Mait HR130 Rotary Piling Rig

Description

Used Mait HR130 Rotary Piling Rig for sale.

8,132 Hours

Capabilities:

– Kelly Drilling

– Max. Drill Depth (Kelly): 40.0m (50.0m w/ limited torque)

-Max. Diameter (Kelly): 1,300mm (1,800mm without lower mast ext.)

Further Specifications:

Upper Carriage (L x W x H): 6.10m x 2.54m x 2.07m

Under Carriage (L x W x H): 4.50m x 2.54m (min) / 3.64m (max) x 1.00m

Engine: CAT C7 ACERT (186 kW @ 2,100 rpm)

Rotary Head (Torque): 170 kNm

Line Pull: 140kN (≈14.0t)

Counterweight: 1,300 kg

Working Weight (Kelly) ≈ 35.0t

Working Height (Kelly) ≈ 17.0m

Kelly Bar: MK130/368/4/40
